Name: Automatic Laser Three Chuck Tube Cutting Machine 3000W For Metal Pipe Tube
Brand: KEBEI LASER
SKU: 350
Price: 40,001.00 USD
Availability: InStock

Product Details

Brand Name: Kebei

Model Number: 350

Payment & Shipping Terms

Minimum Order Quantity: 1unit

Delivery Time: 45 days

Payment Terms: T/T

Supply Ability: 8unitspermonth

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                Automatic Laser Tube Cutting Machine, Three Chuck Tube Cutting Machine 3000W, Automatic Metal Pipe Laser Cutting Machine


Power:	3000-6600W	Cutting Speed:	High Speed
Machine Type:	Three Chuck Tube Cutting Machine	Material:	Metal
Cutting Precision:	High Precision

Power:	3000-6600W
Cutting Speed:	High Speed
Machine Type:	Three Chuck Tube Cutting Machine
Material:	Metal
Cutting Precision:	High Precision

Automatic Laser Three Chuck Tube Cutting Machine 3000W For Metal Pipe Tube

3 Chuck Heavy Tube Processing Pipe Cutting Machine 2000W Power for Metal Pipe Tube Automatic System

Products discription

Three chuck tube cutting machine is standard three-chuck pipe cutting machine with stable and reliable pneumatic chuck structure, three floating supports installed in the machine, intelligent control of support lifting and sheet loading. When cutting, the pipe support can be kept placed in real time, thus avoiding the unstable cutting quality caused by the inertia flinging of the pipe due to high-speed rotation.

Aviation aluminum gantry

● Aerospace grade aluminum light quality

● High speed, good dynamic response,fast acceleration

● Beam as a whole by the finite element analysis optimization of high rigidity Lightweight design, durable

Heavy duty machine frame

● To optimize the design of the sectional welding lathe bed Lathe bed in the middle of reinforcing bar

● Improves the lathe bed stability

● Prevent deformation of lathe bed

Product application

Round tube diameter range 50-450mm (change according to the size of the chuck), can support multiple tube type cutting, channel,
angle, I-beam, etc.; can achieve ultra-long tube cutting, 12 meters loading 12 meters downfeed (expandable) standard
semi-automatic loading, more efficient, convenient and stable

Applicable materials

1. Environmental Engineering

2. Steel Construction

3. Chemical Machinery

4. Petroleum Engineering

5. Ship Transportation

Model	TL350
Power	3000-6600W
X/Y-axis Positioning Accuracy	±0.03mm/m
X/Y-axis Repositioning Accuracy	±0.03mm
No-load Speed	80m/min
Acceleration	0.8G
Rotating Speed of Chucks	80r/min
Cutting Capacity of Round Tube	Φ40-325mm,
Cutting Capacity of Square tube	Φ4040-Φ230230mm
Length of Tube	12000mm
Weight of Single Tube	600kg
Tailing	0
Overall Dimensions (LWH)	29500mm4500mm2700mm

Factory Supply H-Beam Laser Cutting Fiber Construction and Metal Machine Make Marking and Holes Metal Construction

Company introduction

Wuhan kebei international trading Co., Ltd. was established in 2006, with a production base located in the Gedian Economic and Technological Development Zone in the eastern part of Optics Valley. It covers an area of 60 acres, has a standardized factory building of 31000 square meters, and has nearly 400 employees, including nearly 70 research and development personnel. Factory Supply H-Beam Laser Cutting Fiber Construction and Metal Machine Make Marking and Holes Metal Construction .

KEBEI is a high-tech company that integrates the research and development, production, and sales of laser equipment. The company is engaged in the development, production, and sales of intelligent laser processing equipment, including efficient laser processing products such as profile steel laser secondary processing lines, laser cutting machines, laser pipe cutting machines, and laser texturing machines. It is the source manufacturer of full process intelligent laser equipment.

Factory Supply H-Beam Laser Cutting Fiber Construction and Metal Machine Make Marking and Holes Metal Construction

Q: If my machine is broken. Can you repair it for me?

A: Yes. We have free training online. If there is big trouble with your machine in the warranty time, we can repair it.

Q: What factors should be considered when choosing a laser cutting machine?

A: When choosing a laser cutter, consider factors such as the type of material being cut, required accuracy, speed, production cost and machine energy efficiency.
Q: Is the laser cutting machine safe to use?

A: Laser cutters are generally safe to use when proper safety procedures are followed, they can also cause hazards such as burns, eye injuries, and exposure to fumes. Using proper safety equipment and training is crucial.Our production are examined by a series of tests , we can ensure the quality of using.
